Mini-ITX 工業級主機板
AMIX-V1K0
Mini-ITX Motherboard with AMD? Ryzen? Embedded V1000 Series, 4 HDMI/2 LVDS(eDP), SATA III, 3 COM, 5 USB, Dual Intel? GbE LAN.
- AMD® Ryzen™ Embedded V1000 series APU on board
- High Performance “Zen” Core CPU + “VEGA” Graphics GPU
- Four 4K@60 monitors support
- Multi-Display: 4 HDMI 2.0b, 2 LVDS dual-channel (1 co-layout eDP)
- 2 USB 3.1, 3 USB 2.0, 1 SATA III, 3 COM, 2 Intel® GbE LAN
- 1 PCIe (x8), 1 Mini-PCIe w/ micor-SIM, 1 M.2 M-Key 2260 (SSD)
- EuP/ErP 2013 Ready, DC-IN 12V or 19V ~ 24V
- Support TPM v1.2/v2.0 (optional)
主要特色
-
Quad Display
-
Multi Tasking
-
4K Stream
| Model name | AMIX-V1K0 |
| Form Factor | Mini-ITX |
| Dimensions (L)x(W)mm | 170mm x 170mm (6.69" x 6.69") |
| Processor |
AMD? Ryzen? Embedded V1000 series APU V1807B 3.35GHz QC (35-54W) V1756B 3.25GHz QC (35-54W) V1605B 2.0GHz QC (12-25W) V1202B 2.3GHz DC (12-25W) |
| Chipset | AMD? RyzenTM Embedded V1000 APU integrated |
| BIOS | AMI UEFI Flash ROM |
| LAN Controller | Intel ?I211 GbE |
| Audio Codec | Realtek ALC888S |
| Watchdog Timer | Yes |
| Memory | |
| Technology | DDR4 SDRAM support ECC, up to 3200 MT/s |
| Max. Capacity | Up to 32GB |
| Socket | 2 x 260-pin SO-DIMM |
| Display | |
| Graphic | AMD? VEGA graphics |
| Display Interface | 4 x HDMI v2.0b (2 x co-layout LVDS 2ch), 2 x LVDS (Dual channel 18/24-bit)(1 x co-layout eDP v1.4) |
| I/O | |
| Expansion Slot | 1 x PCIe x8, 1 x Mini-PCIe (Full-size w/ micro-SIM), 1 x M.2 M-key 2260 (SSD) |
| LAN | 2 x 10/100/1000 Mbps |
| Serial ATA | 1 x SATA III support SATADOM |
| Audio | Line-in, Line-out, Mic-in |
| USB | 2 x USB 3.1, 3 x USB 2.0 |
| COM | 2 x RS-232, 1 x RS-232/422/485 |
| Display | 4 x HDMI v2.0b, 2 x LVDS (1 x co-layout eDP optional) 1 x eDP (optional) |
| Digital I/O | 4-in/4-out |
| SMB | 1 |
| PS/2 | N/A |
| Power Requirement | |
| Power connector | ATX 2x2-pin, DC-in Jack 4-pin |
| Power Type | DC-in 12V or 19~24V |
| Power Mode | AT/ATX (by jumper selection) |
| Environment | |
| Storage Temperature | -40°C ~ 80°C (-40°F ~ 176°F) |
| Relative Humidity | 0% ~ 95% (non-condensing) |
| Operating Temperature |
0°C ~ 60°C (32°F ~ 140°F) standard -20°C ~ 70°C ( -4°F ~ 158°F) optional -40°C ~ 70°C (-40°F ~ 158°F) optional |
